Case · UBC Vancouver

Helic Arc Display over Vancouver

by Runnan Lin

22° haloSun dogsCircumzenithal arcTangent arcsParhelic circle46° halo120° parheliaParry arcsLowitz arcsHelic arc

Even though it's hard to spot halos on those scattered cirrus, we can clearly see rare halos with stacked pictures. Helic arc unexpectedly showed up twice before and after the noon. The display starts with a nice set of Lowitz and Parry arcs.

22° Halo and Upper Lowitz Arc
22° Halo and Upper Lowitz Arc4 Oct 2026, 10:25:49 to 10:43:16 · 35 stacks of 20 · the sun followed · USM 500 % / 50 px
Upper Lowitz Arc and Parry Arc
Upper Lowitz Arc and Parry Arc4 Oct 2026, 10:25:49 to 10:43:16 · 35 stacks of 20 · the sun followed · USM 500 % / 50 px, then B−R
4 Oct 2026, 13:38:14 to 13:56:12 · Processed with Photoshop
4 Oct 2026, 13:38:14 to 13:56:12 · Processed with Photoshop
Helic Arc
Helic Arc4 Oct 2026, 13:38:14 to 13:56:12 · 36 stacks of 20 · the sun followed · USM 500 % / 50 px

Helic arcs are easier to see in the time-lapse videos.

06:0007:0008:0009:0010:0011:0012:0013:0014:0015:0016:0017:0018:0019:0020:00The displayThe display: 09:48 to 18:36Sun dogsSun dogs: 09:48 to 18:3322° halo22° halo: 09:50 to 16:10Circumzenithal arcCircumzenithal arc: 10:09 to 11:30Circumzenithal arc: 15:04 to 15:58Lowitz arcsLowitz arcs: 10:10 to 12:11Lowitz arcs: 12:22 to 15:31Lowitz arcs: 16:19 to 16:30Parry arcsParry arcs: 10:11 to 12:15Parry arcs: 12:49 to 14:4146° halo46° halo: 10:53 to 11:2946° halo: 11:38 to 14:4846° halo: 14:59 to 16:02Parhelic circleParhelic circle: 11:15 to 16:21120° parhelia120° parhelia: 11:18 to 16:34Helic arcHelic arc: 11:43 to 12:09Helic arc: 13:40 to 13:57Wegener arcsWegener arcs: 11:52 to 12:12
HaloWhenLasting
The display09:48–18:368 h 48 min
Sun dogs09:48–18:338 h 45 min
22° halo09:50–16:106 h 20 min
Circumzenithal arc10:09–11:30, 15:04–15:582 h 15 min
Lowitz arcs rare10:10–12:11, 12:22–15:31, 16:19–16:305 h 22 min
Parry arcs10:11–12:15, 12:49–14:413 h 56 min
46° halo10:53–11:29, 11:38–14:48, 14:59–16:024 h 48 min
Parhelic circle11:15–16:215 h 06 min
120° parhelia11:18–16:345 h 16 min
Helic arc rare11:43–12:09, 13:40–13:5743 min
Wegener arcs rare11:52–12:1221 min

Also seen that day: Tangent arcs.

The halos of the day as they were marked on the camera’s pictures: a rare display. Times are local.
Sunup to 36° highHalos seen3 km6 km9 km12 kmCloudice above 6 kmwater belowHalo chancethe model’s, 0 to 100 %Rainnone422122344443221Wind, groundkm/h516166646364656769727375788083Wind, 9 kmwhere cirrus drifts06:0007:0008:0009:0010:0011:0012:0013:0014:0015:0016:0017:0018:0019:0020:00
The weather over the camera hour by hour, as the model had it (ECMWF IFS 0.25°, from Open-Meteo). Cloud is drawn by height; arrows point where the wind blows, with its speed in km/h. Times are local.
Original Video
Stacked Video
